Taidacent KQ-130K+ High Power Fast Power Line Carrier Communication Modem PLC PLCC Powerline Carrier Module for Power Outage
€136.81
€228.02
Free Shipping Sitewide
-
Order within 3 hours and 19 minutes to get between June 14 - June 20 -
Tracked Shipping on All Orders
-
14-Day Returns
- Secure Payments
-
24/7 Customer Support
Description
- 1. The carrier board integrates the KQ-330/2 module and peripheral circuits. It does not require other coupling components and can be directly connected to 220V AC power. The external dimensions are 50x37x22 mm (Lx0xH), and the pins are led out in a single row (see the figure below).
- 2. The pins are connected to the 220V AC power supply without direction (1st pin, 2nd pin spacing 762mm), the spacing between pins 2 and 3 is 31.5mm, and the spacing between the remaining pins is 2.54mm. The operating frequency is 120-135KHZ, and the interface baud rate is 9600bps. The actual baud rate is 2400BPS/4000BPS.
- 3. The maximum length of a continuous transmission frame is 252 bytes, and the module will not send more data. 4. Receiving sensitivity 1mv 5. Out-of-band suppression = 60dB 6. Normal bandwidth 10KHZ 7. Insulation resistance 500V>500MQ
- 8. Power supply: direct liquid +12V swing receiving 15mA sending about 300mA, not more than 460mA according to load conditions 9. Power frequency insulation withstand voltage: 3000V1min between AC and 0ND without breakdown, no leakage current.
- 10. Lightning protection: TVS tube protection in the computer board, from PCB board wiring to phase selection are based on wide temperature, high voltage, high voltage impact design. 11. Working temperature: 25C-70C star degree <90%
